Fixed Flow Calibration Gas Regulator — C-10, Brass Nickel-Plated (1740 psi)
$108.00
Sale price
$108.00
Regular price
Skip to product information
Fixed Flow Calibration Gas Regulator — C-10, Brass Nickel-Plated (1740 psi)
$108.00
Sale price
$108.00
Regular price
Single-stage fixed flow regulator rated to 1740 psig (120 bar) with a stainless steel 0–3000 psi gauge — the higher-pressure version of our standard C-10 fixed flow regulator, for fully charged high-pressure disposable cylinders. Delivers a constant, factory-preset flow rate for calibrating handheld gas detectors. Fits C-10 calibration gas cylinders. Flow rate is factory-preset to your requirement.
Specifications
| Type | Fixed flow, single-stage (preset) |
| Body / Cap | Brass, nickel-plated |
| Piston | Brass |
| Seats & Seals | PTFE, Viton |
| Inlet connection | C-10 (5/8"×18 UN) |
| Outlet connection | 3/16" (4.8 mm) hose barb |
| Max inlet pressure | 1740 psig / 120 bar |
| Outlet pressure | 60 psig / 4.1 bar |
| Preset flow range | 0.1–8.0 LPM (specify at order) |
| Gauge | Stainless steel, 0–3000 psig / 220 bar |
| Gas compatibility | Non-reactive gases |
| Weight | 0.300 kg |
| Warranty | 12 months |
Applications: Calibration gas delivery and bump testing for handheld gas detectors with non-reactive gases.
