Demand Flow Calibration Gas Regulator — CGA600, Brass Nickel-Plated
$251.00
Sale price
$251.00
Regular price
Skip to product information
Demand Flow Calibration Gas Regulator — CGA600, Brass Nickel-Plated
$251.00
Sale price
$251.00
Regular price
Demand flow regulator for CGA600 calibration gas cylinders (17 L and 34 L steel). Opens only when the instrument's pump draws gas and shuts off automatically, so pump-equipped detectors, docking stations and sampling instruments take exactly the volume they need with no waste. Nickel-plated brass for non-reactive gases.
Specifications
| Type | Demand flow (automatic on/off) |
| Body / Neck | Brass, nickel-plated |
| Piston | Brass |
| Seats & Seals | PTFE, Viton, Buna-N |
| Diaphragm | Buna-N |
| Inlet connection | CGA600 (1"×20 UNF) |
| Outlet connection | 3/16" (4.8 mm) hose barb |
| Max inlet pressure | 600 psig / 41 bar |
| Flow | 0–3.0 LPM, as demanded by the instrument |
| Max vacuum required for 3.0 LPM | 3" H2O / 5.6 mm Hg |
| Gauge | Brass, 0–600 psig / 41 bar |
| Gas compatibility | Non-reactive gases |
| Weight | 0.450 kg |
| Warranty | 12 months |
Applications: Pump-based gas detectors, docking stations and sampling instruments using 17 L and 34 L CGA600 steel cylinders.
